» Gourjon differential Galvanometer (0534)
Immagini
DESCRIPTION
Exhibit 534 is a Gourjon differential galvanometer with two separate windings on a single coil placed beneath the visible dial. The windings can be combined in series to provide one strong field or in opposition to provide a difference field. The resulting field rotates the N-S needle inside the coil and the S-N needle in the same direction in the return field so as to be independent of the earth's magnetic field (astatic configuration invented by Nobili). The S-N needle then serves as indicator on the visible dial. The instrument is protected by a bell jar fixed on the brass base supported by three adjustable screws for leveling.ISCRIZIONI
- La Tète de l'Aiguille dèvie en A ou en B selon que la Courant entre par a ou b.
- T. Gourjon
Dati Catalografici
| Data di costruzione: | --- |
|---|---|
| Data di carico: | 1850 |
| Nr. Inventario: | 985 (Generale dal 1874) 537 (Antico inv. Gabinetto Fis) |
| Costruttore: | T.Gourjon |
| Materiale: | ottone, vetro, carta, metallo |
| Dimensioni: | diametro massimo cm 16; altezza cm 26 |
| Conservazione: | buono (Manca il filo di sospensione degli aghi) |
