» Rudolph Koenid Lissajous Apparatus (0701)
Immagini
DESCRIPTION
Exhibit 701 is a Lissajous figure generating system based on the use of 8 steel tuning forks mounted on wood parallelepipeds and conserved in a wood case. Some accessories (horizontal and vertical supports and the U-shaped bench) that serve to mount the tuning forks for displaying the Lissajous figures on a screen are missing. Each tuning fork has a square hard wood handle and has on its arms brass disks, one which carries a mirror and the other a weight for balance and long duration of the vibrations. Four tuning forks have fixed frequencies while the others carry sliders which can be fixed in different positions: for each position the frequency is inscribed.
The list of the tuning forks and their relative characteristics can be read from the base or from each tuning fork.
BIBLIOGRAPHY
Dati Catalografici
| Data di costruzione: | Seconda metà XIX secolo |
|---|---|
| Data di carico: | 1873-09-01 |
| Nr. Inventario: | 346 (Generale dal 1874) |
| Costruttore: | Rudolph Koenig |
| Materiale: | acciaio |
| Dimensioni: | cassetta: 59 cm x 35 cm x 11 cm |
| Conservazione: | buono (La cassetta ha delle fessure; i diapason sono in ottimo stato ma per poterli usare mancano alcuni supporti. ) |
