» Hartmann & Braun resistance box (0550)
Immagini
DESCRIPTION
Exhibit 550 is a variable resistance box in which a known resistance is inserted into the involved circuit by removing the key associated with a given value. The values vary from 0.1 to 4000 Ohms arranged in five rows where each row has values 10 times the value of the preceding row.
ISCRIZIONI
- Inciso: "Hartmann & Braun A. G.¶
Frankfurt A.M.¶
N° 15747" - Su un lato è scritto: "Charge: les resistences de ces rheostats peuvent supporter les intensites de courant indiquees ci-apres, sans qu'il en resulte pour elles aucune avarie ni aucun changement de valeur notable:
_______________________________________________________________________ |Résistance en ohms |0,1-0,4|1-4 |10-40|100-400|1000-4000|10000-40000| |---------------------|-------|----|-----|-------|---------|-----------| |Intensité max. | 1,5 |0,8 |0,25 | 0,08 | 0,03 | 0,008 | |admissible en amperes| | | | | | | ------------------------------------------------------------------------ G.-A.N: 198f 100 1.27 H
Dati Catalografici
Data di costruzione: | --- |
---|---|
Data di carico: | sconosciuta |
Nr. Inventario: | Ignoto (Ignoto) |
Costruttore: | Hartmann & Braun A. G. |
Materiale: | ottone, legno, bakelite |
Dimensioni: | 27,1 cm x 20 cm x 13,5 cm |
Conservazione: | ottimo |
